HP  70db Latching Step Attenuator  DC-4 GHz















This Attenuator will step from 0 to -70 db in 10 db steps. A 35 ms or longer low or ground is applied to the indicated pins and this unit will latch at that attenuation. The relay does not drar current after the latch.
